■ Specifications（T=±25℃）
| Performance Parameter | Unit | Technical Indicator |
|---|---|---|
| Average Wavelength | nm | 1530±2 |
| Average Wavelength Stability | ppm | ≤30 |
| Spectral Waveform | / | Gaussian type |
| Half - value Spectral Width | nm | 6~7 |
| Spectral Modulation Depth (ripple) | dB | ≤0.1 |
| Fiber Output Power | mW | 10 |
| Stability Of Fiber Output Power At Room Temperature | / | ≤1 |
| Stability Of Aber Output Power At Full Temperature | / | ≤3% |
| Degree Of Fiber Output Polarization | dB | < 0.2 |
| Pigtail Type | / | SM fiber |
| Pigtail Length | m | ≥1.2 |
| Length Of Pigtail Sheath | mm | 60 - 100 |
| Dimensions | mm | According to gyroscope size |
| Operation Temperature | °C | -40~+70 |
| Humidity Range | / | 5%~98% |
■ Absolute Maximum Rated Parameter（T=±25℃）
| Technical Indicators | Unit | Min | Max |
|---|---|---|---|
| Operating voltage | V | 3.0 | 5.0 |
| Operating temperature | °C | -40 | +70 |
| Storage temperature | °C | -40 | +70 |
